Print Head

 Dual Epson I3200-E1 Print Head

Ink

 EPI2-2 Years Durability Eco Solvent Ink

Color Config.

 K.C.Y.M.

Ink Supply System

 Bulk Ink Supply System with Ink Recirculation

Ink Tank

 1500ml

Printing Width

 Max. 1620mm

Media Type

 Banner, Coated PP, Vinyl, PVC Film…

Roll Diameter

 Max. 300mm

Roll Weight

 Max. 50KGS

Core Diameter

 3 in (76.2mm) or 2 in (50.8mm)

Printing Speed

 Mode                     Resolution                  Output

 Draft                     360×1200dpi                71㎡/h

 Production            360×1800dpi                51㎡/h

 High-Res              720×1200dpi                40㎡/h

 Photo                    720×1800dpi                27.5㎡/h

Data Interface

 External: Ethernet; Internal: Fiber Optical

Working Environment

 Temp. 23℃~29℃, Humidity: 50%~80%

Software

 FlexiPRINT / Onyx (Optional)…+ GZ Printer Manager

Power

 Single Phase, 50Hz / AC, 220V±10%, 6.7A (Printer)+25A (IR Dryer)

Packed / Installed Size

 LxWxH(mm)：2920x1050x750 / 2790x870x1520

G.W. / N.W.

 372KGS / 272KGS
