Print Head

 2x Epson I3200-U1 Print Heads

Curing System

 Dual Water Cooling LED UV Lamps

Ink

 Gongzheng UV Ink: REI-3

Color Config.

 2xKCYM; 1xKCYM+W; W+1xKCMY

Ink Supply System

 Bulk Ink Supply System + White Ink Recirculation & Stirring System

Ink Tank

 1000ml

Printing Width

 Max. 1600mm

Media Type

 Banner, Coated PP, Vinyl, Backlit Textile, PVC Film, PET Film…

Roll Diameter

 Max. 300mm

Roll Weight

 Max. 50kgs

Core Diameter

 3 in (76.2mm) or 2 in (50.8mm)

Printing Speed

 Mode                      Resolution                1xW+1xKCYM              2xKCYM

 Draft                      720X1200 dpi                10.5㎡/h                    19㎡/h

 Production             720X1200 dpi                 8.5㎡/h                     17㎡/h

 High-Res               720X1800 dpi                  6㎡/h                       13㎡/h

 Photo                     720X1800 dpi                  5㎡/h                       11㎡/h

Data Interface

 External: Ethernet; Internal: Fiber Optical

Working Environment

 Temp. 23℃~29℃, Humidity: 50%~80%

Software

 FlexiPRINT TX22 / ONYX RIPCenter (Optional).….+GZ Printer Manager

Power

 Single Phase, 50Hz/AC, 220V±10%, 5.7A (Printer+UV Controller)

Packed / Installed Size

 LxWxH(mm): 2920x1050x750 / 2790x870x1520

G.W. / N.W.

 378kgs / 278kgs
